1969 ELB SWB09VAII Surface Grinder | 18" x 36"IDF, Wheel Dresser, Coolant

1969 ELB SWB09VAII Surface Grinder | 18" x 36"IDF, Wheel Dresser, Coolant

$29,500 (USD)

Location:Helena, AL

orCall 205-664-9644

Description

Model: SWB09VAII s/n: 79420269 Year: 1969 Made in Germany Capacity: 18" x 36" Wheel: 16"d x 2"w x 5" bore Distance from chuck to spindle: 24" Speeds: 3-82 ft/min Automatic Cross feed continuous: 47 in/min Automatic Cross feed intemittent: 0.04 - 2.4 in/stroke Cross feed on handwheel: 0.001" Cross feed fine adjustment: 0.0005 Automatic Vertical rapid: 6 in/min Vertical feed on handwheel: 0.0001 1 division ins Vertical feed on fine setting knob: 0.00005 1 division ins Dowfeed: 0.0001 - 0.0025 in/impulse Motor: 14.7 HP Equipped With: 19-3/4" x 35-1/2" Electric Magnetic Chuck IDF Coolant Over the wheel dresser Overall Size: 112" L x 87" W x 108" H x 14,500 lbs (approx) Coolant tank: 27" L x 52" W x 24" H x 500 lbs (approx)


Freight charges are not included in sale price. Freight scheduling and costs are responsibility of the buyer. Packaging charges to ensure safety of equipment during transport for arrival on buyers truck will be added when applicable.

Specifications

ManufacturerElb
ModelSWB09VAII Surface Grinder
Year1969
ConditionUsed
Stock Number7820
