1976 Summit VBM | 59" 4 Jaw Chuck, 70" Swing, 47"UR, Ram, Turret & Side Heads

1976 Summit VBM | 59" 4 Jaw Chuck, 70" Swing, 47"UR, Ram, Turret & Side Heads

$55,000 (USD)

Helena, AL

orCall 205-664-9644

Description

S/N:15A-361 Year: 1976 (approx) CATALOGUE SPECIFICATIONS: Table Diameter......................................... 59" Swing Maximum, w/o Side Head........................... 70" Swing Maximum, w/Side Head............................. 65" Height Under Cross-Rail, Maximum....................... 47.25" Vertical Travel of Side Head........................... 45" Cross-Rail Travel, Vertical............................ 39" Ram-Head Travel, Vertical.............................. 33.5" Ram-Head Swivel, Degrees............................... 35-DEGREES Side-Head Travel, Vertical............................. 45" Side-Head Travel, Horizontal........................... 26.5" (18) Table Speeds, Range............................... 4 to 165 RPM Feeds, Range........................................... 0.05 to .50 IPR Cross-Rail Speed....................................... 14 IPM Rapid Traverse Rate.................................... 98 IPM Main Motor, Horsepower................................. Freight charges are not included in sale price. Freight scheduling and costs are responsibility of the buyer. Packaging charges to ensure safety of equipment during transport for arrival on buyers truck will be added when applicable.

Specifications

ManufacturerSummit
ModelVBM
Year1976
ConditionUsed
Stock Number7727
