1978 American 4025-31 engine lathe | 46" x 396"

1978 American 4025-31 engine lathe | 46" x 396"

$89,900 (USD)

Helena, AL

orCall 205-664-9644

Description

SPECIFICATIONS: Swing Over Bed: 46 1/2" Swing Over Carriage Wings: 44" Swing Over Cross Slide: 31" Center Distance (33 ft): 396" Domestic Shipping Weight: 54,550 lbs Max Size Motor Recommended: 60 HP Coolant Capacity - Base Length: 60 Gal Length of Bed: 49 1/2" Hole in Spindle: 2 7/8" Number of Spindle Speeds: 27 Taper of Center: #6MT High Range 27 Speed Head: 9 - 900 RPM Medium Range 27 Speed Head: 71/2 - 750 RPM Low Range 27 Speed Head: 6 - 600 RPM Spindle Radial Load Capacity Front Bearing at 100 RPM: 53,300 lbs Center Bearing at 100 RPM: 29,300 lbs Spindle Thrust Load Capacity Front Bearing at 100 RPM: 47,600 lbs


Freight charges are not included in sale price. Freight scheduling and costs are responsibility of the buyer. Packaging charges to ensure safety of equipment during transport for arrival on buyers truck will be added when applicable.

Specifications

ManufacturerAmerican
Model4025-31 engine lathe
Year1978
ConditionUsed
Stock Number6230
