Sharp SED-403 Sinker EDM, Heidenhain Control, 1191.5 hours, 1997

Contact us for price

Helena, AL

orCall 205-664-9644

Description

Model: SED-403 EDM
S/N: 9062287
Year: 1997
Hours: 1191.5
Machine Specifications:
Work Table Size............................25.6" x 15.7"
X & Y Travel...............................15.7 x 11.8"
Ram Servo Travel...........................13.7"
Ram Platen To Work Table...................11.45"-25.1"
Max. Electrode Weight......................165 Lbs
Max. Work Piece Weight.....................1,760 Lbs
Work Tank Capacity.........................44" x 22" x 13.4"
Weight Of Machine Unit.....................3,080 Lbs
Dimensions(W x D x H)......................59" x 71" x 91"
Equipped With:
Heidenhain H50-3A Control
Halogen Work Light
Paper Filter(2)
Clamping Kit
Electrode Holder
Flushing Nozzle(3)
Drill Chuck
Tool Box

Specifications

Conditionused
Stock Number7441
